800G
Hot-pluggable OSFP form factor
8×106.25Gb/s with PAM4 optical interface
8×106.25Gb/s with PAM4 electrical interface
MPO-16 APC Optical Connector
Operating case temperature: 0 to 70℃
Single 3.3V power supply
I2C Interface with Integrated Digital Diagnostic Monitoring
Maximum power consumption 18W
RoHS compliant
8×106.25Gb/s with PAM4 optical interface
8×106.25Gb/s with PAM4 electrical interface
MPO-16 APC Optical Connector
Operating case temperature: 0 to 70℃
Single 3.3V power supply
I2C Interface with Integrated Digital Diagnostic Monitoring
Maximum power consumption 18W
RoHS compliant
| Part Number | Description | λ(nm) | Data Rate(Gb/s) | Reach | Package | Connector |
| SO0A88KK-OMGA | OSFP112 800G SR8 | 850 | 800 | 100M(OM4) | OSFP112 | MPO16 |
| SO0A33KK-OMGA | OSFP112 800G DR8 | 1310 | 800 | 500M | OSFP112 | MPO16 |
